The SPD-RS485-101
Photoelectric leakage sensor employs two detection principles: photoelectric detection and electrode detection. It can detect and distinguish between conductive liquids and non-conductive liquids. The structure adopts a full plastic encapsulation design, and the electronic components are less affected by environmental factors, ensuring the high precision and reliability of the product. The product features high sensitivity, fast response time, ease of use, and convenient installation. The 485 signal output by the sensor can be integrated with various monitoring systems to achieve remote monitoring.
The SPD-RS485-101 sensor uses industrial-grade electronic components, which can not only ensure high sensitivity during detection but also reduce false alarms caused by various external factors. It adopts electromagnetic compatibility design and has protection functions such as surge protection, static electricity protection, and EFT protection.
The SPD-RS485-101 sensor combines photoelectric and electrode detection principles to simultaneously detect the leakage of conductive liquids and non-conductive liquids, and can reliably distinguish the type of leaked liquid.
The status indicator light (red and green dual-color light) of the SPD-RS485-101 sensor can indicate two states: normal and leakage alarm. In the normal state, the green light is always on, and in the leakage alarm state, the red light is always on.
RS-485 communication method. The sensor can output RS485 signals to connect with the monitoring platform and report real-time environmental monitoring data. The communication distance can reach up to 1200 meters.
