High Stability: Uses industrial-grade CPU processors and components, with a fully steel-structured chassis, providing higher stability and suitable for various occasions.
Comprehensive Functionality: Has functions for detecting power outages, temperature and humidity, smoke sensors, water immersion, gas, etc., and can monitor and control equipment such as air conditioners, UPS, constant temperature integrated machines, generators, etc.
External Self-Power Supply: Comes with an external power supply interface, supporting direct power supply to the equipment, simplifying wiring.
Construction and Installation: Standard 1U rack design for installation.
Secondary Development: Open interfaces and protocols for secondary development and integration.
Service Life: After more than ten years of technological upgrades and optimizations, with its outstanding reliability, the service life is long.
| Parameter Item | Specification |
|---|---|
| Product Size | 440×280×44mm (Length * Width * Height) |
| Power Input | AC 220V (optional dual power input), power consumption <80W |
| Working Environment | Temperature -10℃～50℃, humidity 10%～90%RH, no condensation |
| CPU | 1J1900 (optional higher-performance CPU) |
| Host Memory | 1x SO-DIMM, DDR3 1333MHz Memory, 4G (optional 8G) |
| Host Hard Disk | Mechanical hard disk 500G (can increase hard disk capacity or choose solid-state drive) |
| Host Serial Ports | 2 RS232, 6 RS485 serial ports |
| USB Interfaces | 4 USB ports |
| Ethernet Card | 1 10/100/1000M Ethernet port |
| EMC Indicators | Electrostatic protection, contact discharge ±6KV, air discharge ±8KV. EFT protection ±2KV |
| Installation Method | 1U standard rack installation |
Covering industries: finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, etc.
Application Scenarios: power environment monitoring systems in computer rooms, power distribution rooms, factories, workshops, warehouses, etc.
High Stability: Uses industrial-grade CPU processors and components, with a fully steel-structured chassis, providing higher stability and suitable for various occasions.
Comprehensive Functionality: Has functions for detecting power outages, temperature and humidity, smoke sensors, water immersion, gas, etc., and can monitor and control equipment such as air conditioners, UPS, constant temperature integrated machines, generators, etc.
External Self-Power Supply: Comes with an external power supply interface, supporting direct power supply to the equipment, simplifying wiring.
Construction and Installation: Standard 1U rack design for installation.
Secondary Development: Open interfaces and protocols for secondary development and integration.
Service Life: After more than ten years of technological upgrades and optimizations, with its outstanding reliability, the service life is long.
| Parameter Item | Specification |
|---|---|
| Product Size | 440×280×44mm (Length * Width * Height) |
| Power Input | AC 220V (optional dual power input), power consumption <80W |
| Working Environment | Temperature -10℃～50℃, humidity 10%～90%RH, no condensation |
| CPU | 1J1900 (optional higher-performance CPU) |
| Host Memory | 1x SO-DIMM, DDR3 1333MHz Memory, 4G (optional 8G) |
| Host Hard Disk | Mechanical hard disk 500G (can increase hard disk capacity or choose solid-state drive) |
| Host Serial Ports | 2 RS232, 6 RS485 serial ports |
| USB Interfaces | 4 USB ports |
| Ethernet Card | 1 10/100/1000M Ethernet port |
| EMC Indicators | Electrostatic protection, contact discharge ±6KV, air discharge ±8KV. EFT protection ±2KV |
| Installation Method | 1U standard rack installation |
Covering industries: finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, etc.
Application Scenarios: power environment monitoring systems in computer rooms, power distribution rooms, factories, workshops, warehouses, etc.
