High Stability: It has higher sensitivity, stability, and accuracy, with stronger versatility, expandability, and anti-electromagnetic interference design. It avoids interference caused by various external factors and is suitable for different occasions.
Interface Type: Standard serial port RS485 communication, with a distance of up to 1200 meters.
Installation: The sensor is small in size and light in weight. It can be installed by suspension or wall mounting, making the installation convenient.
Large Screen Display: It uses a large-screen high-brightness LCD display, providing intuitive observation and simple operation.
Service Life: After more than ten years of technological upgrades and optimizations, it has an excellent reliability and a long service life.
| Parameter Item | Specification |
|---|---|
| Product Size | 86862.55mm (LengthWidthHeight) |
| Working Voltage | 12V DC |
| Detection Range | Temperature -40℃～125℃, ±0.5℃; Humidity 0-100%RH, ±3%RH |
| Interface Type | RS485 interface |
| Working Environment | Working temperature -20℃～80℃ |
| Effective Area | 10-30㎡ |
| Communication Protocol | Modbus_RTU |
| Baud Rate | 2400, 4800, 9600, 19200bps |
Covering Industries: Finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, and many other industries.
Application Scenarios: Computer rooms, warehouses, power distribution rooms, factories, workshops, laboratories, etc. Such as computer room monitoring, power monitoring, security monitoring systems, anti-theft alarm systems, power environment monitoring systems, etc.
