| Quantity: | |
|---|---|
High Stability: This product has good sensitivity, strong stability, and wide applicability, suitable for various scenarios.
Interface Type: Standard serial port RS485 communication, HART optional.
Technical Functions: Zero-point tracking function, linear compensation function, and temperature compensation function.
Wide Applicability: Not prone to clogging, easy to clean, suitable for the measurement of liquids in tanks, troughs, and pits, and for the measurement of corrosive liquids.
Construction and Installation: The sensor is small in size and light in weight, making installation and installation convenient.
Service Life: After more than ten years of technological upgrades and optimizations, with its outstanding reliability, the service life is long.
| 序号 | 参数项 | 规格 |
|---|---|---|
| 1 | Measurement Range | 0～1Kpa～2Mpa |
| 2 | Accuracy Grade | 0.25, 0.5 |
| 3 | Explosion-proof Grade | ExiaⅡCT4～CT6 (Intrinsic Safety Type) |
| 4 | Working Voltage | 12.5～36VDC |
| 5 | Range Migration | Can be migrated as a standard ratio of 10:1 |
| 6 | Signal Line Hole | PG16 |
| 7 | Sealing Material | Fluorine rubber, PTFE (Polytetrafluoroethylene) |
| 8 | Vibration Impact | 200Hz/g is 0.01%FS on any axis |
| 9 | Sensor Material | 96% aluminum oxide ceramic |
| 10 | Sensor Shell Material | High-quality stainless steel 316L, PTFE (Polytetrafluoroethylene) |
| 11 | Sensor Protection Grade | IP68 |
Covering Industries: Finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, and many other industries.
Application Scenarios: Computer rooms, warehouses, power distribution rooms, factories, workshops, laboratories, etc., such as computer room monitoring, power monitoring, security monitoring systems, anti-theft alarm systems, power environment monitoring systems, etc.
High Stability: This product has good sensitivity, strong stability, and wide applicability, suitable for various scenarios.
Interface Type: Standard serial port RS485 communication, HART optional.
Technical Functions: Zero-point tracking function, linear compensation function, and temperature compensation function.
Wide Applicability: Not prone to clogging, easy to clean, suitable for the measurement of liquids in tanks, troughs, and pits, and for the measurement of corrosive liquids.
Construction and Installation: The sensor is small in size and light in weight, making installation and installation convenient.
Service Life: After more than ten years of technological upgrades and optimizations, with its outstanding reliability, the service life is long.
| 序号 | 参数项 | 规格 |
|---|---|---|
| 1 | Measurement Range | 0～1Kpa～2Mpa |
| 2 | Accuracy Grade | 0.25, 0.5 |
| 3 | Explosion-proof Grade | ExiaⅡCT4～CT6 (Intrinsic Safety Type) |
| 4 | Working Voltage | 12.5～36VDC |
| 5 | Range Migration | Can be migrated as a standard ratio of 10:1 |
| 6 | Signal Line Hole | PG16 |
| 7 | Sealing Material | Fluorine rubber, PTFE (Polytetrafluoroethylene) |
| 8 | Vibration Impact | 200Hz/g is 0.01%FS on any axis |
| 9 | Sensor Material | 96% aluminum oxide ceramic |
| 10 | Sensor Shell Material | High-quality stainless steel 316L, PTFE (Polytetrafluoroethylene) |
| 11 | Sensor Protection Grade | IP68 |
Covering Industries: Finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, and many other industries.
Application Scenarios: Computer rooms, warehouses, power distribution rooms, factories, workshops, laboratories, etc., such as computer room monitoring, power monitoring, security monitoring systems, anti-theft alarm systems, power environment monitoring systems, etc.
