High Stability: This product has high stability and strong versatility, and can be applied in different situations.
Corrosion and Wear Resistance: It has excellent corrosion resistance and wear resistance.
Rich Interfaces: It has various threaded interfaces and electrical connections.
Installation and Construction: The sensor is small in size and light in weight, and the installation and construction are convenient.
Service Life: After more than ten years of technical upgrade and optimization, with its outstanding reliability, the service life is long.
| Parameter Item | Specification |
|---|---|
| Range | -100kPa to 0.3MPa... 6MPa, 0 to 0.3MPa... 60MPa |
| Accuracy Grade | ±0.5%F.S, ±1.0%F.S |
| Overload Pressure | 1.5 times the rated pressure (maximum up to 80MPa) |
| Breaking Pressure | 2 times the rated pressure (maximum up to 90MPa) |
| Working Temperature | -20 to 85℃ (Storage Temperature: -40 to 100℃) |
| Measured Medium | Gases or liquids compatible with 1Cr18Ni9Ti, 304 stainless steel, fluorine rubber or nitrile rubber |
| Power Supply | 10 - 36VDC (two-wire system default) |
| Shell Protection | IP67, IP65, IP54 |
| Pressure Interface | G1/4, NPT1/4, R1/4, BPS1/4, G1/2, 7/16-20UNF, M201.5, M101, M14*1.5, etc. |
| Pressure Form | Gauge pressure G |
| Stability | < 0.5%FS per year |
Covering Enterprises: Finance, communication, government affairs, transportation, logistics, factories, warehouses, medicine, and many other industries.
Application Scenarios: Computer rooms, warehouses, power distribution rooms, factories, workshops, laboratories, etc., such as computer room monitoring, power monitoring, security monitoring systems, anti-theft alarm systems, power environment monitoring systems, etc.
